F14 circle piece for Ø 4,0m 45°, 255.00 CHF

Similar items

The F14 truss series by Global Truss is a TÜV approved 4-point system with an external dimension of 10cm. The small footprint of the truss is perfect for shop fitting and constructions with minimal loads. A maximum span of up to 7 meters can be used.

&nbsp.

The F14 truss is built with 20 x 2mm main tubes and 6mm diagonal braces of aluminium, whilst the extra end frame improves the stability of the truss. The truss lengths are connected with the included conical connectors. This truss and all other Global Truss series can be powder coated in every RAL colour.

General

Colour Aluminum
TÜV certificate No
Material Al EN AW-6061 T6

Technical Data

Number of points 4-point
Edge dimension 10 cm
System F14
Type circle

Circle

Diameter circle 4000 mm
Excerpt 45°

main pipe

Diameter main pipe 20 mm
Wall thickness main pipe 2 mm

Brace

Diameter Brace 6 mm

Hardware

Weight 2,60 kg
