3 C - 45° Curve for 85002 Cable Protector 3-channel
RRP 200.00 CHF
164.00 CHF *
deliverable
Description
Technical data
#dzm_niuplus_companion.niu_quick_buy_variations#
All variations to this product.Description
Productinformation in detail 3 Big Channels - Most Popular
Featuring a 73 mm profile, 45° curve and end ramps with detachable dovetail connectors the Defender® 3 cable protection system provides versatile cable routing and safe crossing for vehicles and pedestrians. With 3 medium large channels, built-in handles for easy portability and a 5 t per 25 x 30 cm load capacity the 73 mm profile Defender® 3 cable protectors are the perfect all-round choice for a wide variety of applications including heavy wheeled traffic, construction sites, warehouses, carnivals, fairs, trade shows, exhibitions, shopping malls and music events.
Label your cable protector! Customise the Defender cable protector with your company logo for orders ex 30 pieces for each product. You will find the format requirements in the download pool above the text. Feel free to contact us for more information.
Technical data
| Product type | Cable Protectors |
| Type | 3 Channels |
| Width | 605 mm |
| Height | 75 mm |
| Length | 1005 mm |
| Channels | 3 |
| Width channel 1 | 52 mm |
| Height channel 1 | 49 mm |
| Width channel 2 | 45 mm |
| Height channel 2 | 50 mm |
| Width channel 3 | 52 mm |
| Height channel 3 | 49 mm |
| Material | Polyurethane |
| Max load | Approx. 5 t on a surface area of 25 x 30 cm |
| Chemical resistance | Oil-resistant |
| Chemical resistance | Petrol-resistant |
| Chemical resistance | Short-term contact with solvents |
| Hardness range | 88 Shore ± 4 Shore |
| Fire protection class | B2 |
| Temperature range | -40 to +70 °C |
| Weight | 23,01 kg |
| Special feature | Available also in B1 |
| Special feature | Inclusive 2 connector plugs |
