In Multi-card mode, the controller can be used as two independent controllers, making the images of two input sources perfectly displayed on the screen.
MCTRL4K also supports HDR function combined with A8s/A10s receiving card to greatly enhance the image quality of the screen, presenting more vivid and clearer images.
Controlling the device can be done by USB or Ethernet combined with the Novastar (smart) LCT software but it also has a build-in web interface for remote control.
If you need to cover a large distance between controller and Led screen, the MCTRL4K setup can be combined with CVT4K-S fibre convertor(101653) and 10G SFP modules(101623)
The MCTRL4K controller is mainly applied for medium to large events, control centres, security monitoring, Olympic Games and various sports centres.
|Product weight:||7.70 Kg|
Capacity: > 8.2 million pixels
Control Method: USB / Network Interface
Video Interface: 1x DP1.2 / 2x dual-link DVI / 1x HDMI 2.0
Video Format: RGB444, YCbCr4:2:0, YCbCr4:2:2, YCbCr4:4:4
Bit Depth Of Video Resource: 8/10/12bit
Output Interface: 16 Ethernet output ports
Output Interface: 4 x Fibre output ports, OPT1(out1-8); OPT2(out 9-16); OPT3/4 are backup for OPT1/2
Note: Fibre port will only work with 10GSFP modules(101623) and CVT4K-S (101653)
GENLOCK: Input and Loop
Supply Voltage: AC-100-240V-50/60HZ
Power consumption: 30Watt
Dimensions: 482.6x372x96mm (including handles)
Dimensions: 435.6x330x 89mm (width without handles)
Operating temperature: -20 ~ +60°
Operating humidity: 10% RH?90% RH, non-condensing
Certifications: FCC / RoHS / UL&CUL / EAC / CB / IC / CE
For most recent software please check Novastar website: http://www.novastar.tech/download/
